Frame
18-gauge galvanized steel
Blades
20-gauge roll-formed galvanized steel
Features
Wall louvers are self-mulling, self-flashing and self-framing. No other trim required. Wall louvers are chemically treated before painting. Louvers can be painted to match pre-selected colors by manufacturer. Standard paint is an electrostatically applied powder paint, 3 mm thick with an oven-baked finish.
Insect Screen
Aluminum screen cloth installed in an extruded removable, rewireable aluminum frame
Blade Operators
Twin-link brackets plated steel assembled with double brass pivot and set screw
Connecting Rod
¼” zinc plated steel
Operator
Standard operator is by a reinforced cast aluminum hand crank. Optional: Chain operator of #35 sash chain with plastic-coated chain pull handle
NOTE: Please specify panel type when ordering your wall louver. The frame has a recessed head to accept the wall panel and side flanges fit specified panel profile on 1’ modules. The sill is tapered to provide drainage and exclude moisture. Flat flange louvers are also available for installation into framed openings.
Additional Notes
All welds are watertight and made from non-corroding siliconized bronze wire and finished after fabrication.
Additional materials available include stainless steel, aluminum and Galvalume. All louvers are shipped with an 18 x 16 aluminum insect screen mounted in a removable, rewireable frame. Hardware cloth is also available. Wall louvers are shipped individually in heavy-duty cardboard cartons.
